Product Information

Configure your perfect audio setup.

Designed to enhance your in-car audio experience, the powerful GM-A3702 gives you total installation freedom and very low distortion. With a one-body heat sink and gain adjustment of up to 6.5V, you can turn your in-car audio experience into the sound staging environment that you’re looking for.

The GM-A3702 offers support for 2 Ohm and 4 Ohm speakers, and can produce up to 500 W of power when bridged.

Specification

• Maximum power    500W (Bridged) or 2 x 170W (4 Ω) or 2 x 250 W (2 Ω)
• CEA 2006 Power    2 x 60W (4 Ω)
• Continuous power output    2 x 60W (4 Ω) or 1 x 190W (4Ω bridged) or 2 x 95 W (2 Ω)
• Load impedance capability    2-8 ohm allowable (Stereo)
• Frequency response    10Hz ~ 70kHz (+0dB , -3dB)
• Distortion    < 0.05 %
• S/N ratio    > 95 dB
• LPF    80 Hz (-12 dB/oct)
• Chassis size (W x H x D)    246(W) x 60(H) x 180(D)
• Unit weight    1.4
• Speaker Terminals    Screw-type
• 2-channel

What's Included

• Pioneer GM-A3702
• Manual
