Product Information

Flexible and Fun

Using Class A/B power, this amp features a variable bass boost with KickEQ™, giving you as much as a 6dB of extra bump. A powerful 12dB crossover is also included, letting you quickly tune your system to perfection.

CX-Series Amplifiers accept up to 40 volts (400 watts) of speaker-level input signal. This kind of flexibility both makes line-out converters unnecessary and optimizes your sound quality at the same time!

Highly efficient heat sinks keep the amp cool with a sophisticated new look, while KICKER’s FIT+™ (Fail-safe Integration Technology-PLUS), gives you outstanding noise rejection - even with premium factory audio systems.

This CX-Series Amplifier delivers as much as 90 watts into four full-range channels, or 180 watts into two bridged channels. See below for more details.

• Class A/B full-range channels
• Three-second turn-on/off delay to eliminate unwanted interference
• Variable 12dB crossovers provides control to dial in perfect sound
• KickEQ™ 6dB variable bass boost for those additional low frequencies
• FIT+™ (Fail-safe Integration Technology-PLUS) means it works with nearly every radio
• Accepts up to 40-volt input signal
• Small footprint for easier installation
• Vertical mounting hardware included for another unique look
• Compatible with CXARC Remote Bass Control (AMP2 must be in LO-PASS X-OVER mode)

Specification

• MODEL CXA360.4
• Power (watts/ch) 4 Ohm Stereo 65x4
• Power (watts/ch) 2 Ohm Stereo 90x4
• Power (watts/ch) 4 Ohm Mono 180x2
• CXARC Remote Bass Capable (sold sep.) Yes
• Dimensions (in, cm): (all models 2-3/8, 5.9H x 6-3/4, 17W x ...L) 12-1/2, 31.7
• Frequency Response (Hz): 10Hz-20kHz
• Input Sensitivity: 125mV–5V (Low Level) 1V–40V (High Level)
• Signal-to-Noise Ratio: 95dB
• Active Crossover: HI, LO or OFF; Variable 50–200Hz @ 12dB/Octave
• Subsonic Filter: n/a
• KickEQ™ Boost Variable 0-6dB @40Hz

What's Included

• CX360.4 4 Channel Amplifier
