Product Information

5-Channel Class D System Amplifier with Integrated DSP, 100 W x 4 @ 2 Ω + 600 W x 1 @ 2 Ω - 14.4V

Designed to simplify great audio, every VXi amplifier combines our advanced NexD2™ switching amplifier technology with an integrated, full-featured digital signal processor.

Employing our second generation NexD2™ amplifier technology, the VX1000/5i efficiently powers a complete audio system. It can drive four main speakers with 75 W x 4 @ 4 ohms while also powering a subwoofer with up to 600W @ 2 ohms. Bridging the main channels converts it into a very powerful, 3-channel system amplifier with up to 200W x 2 @ 4 ohms on the main channels and 600W @ 2 ohms on the subwoofer channel.

The NexD2™ full-range technology in the main channels of this amplifier is DSP-controlled and features a reduced loop area design utilizing DirectFET™ outputs for outstanding fidelity, very low noise and exceptional efficiency. The subwoofer channel features an optimized low-frequency variant of the NexD2™ technology. The amplifier chassis is ultra-compact, with all connections on one side, to greatly simplify installation into tight spaces.

Instead of traditional control knobs and switches, all amplifier adjustments and DSP functionality are configured via a compatible external device (PC, Tablet or Smartphone), with the appropriate JL Audio TüN™ Software application installed.

Amplifier includes: Power Connector (for 2 AWG wire), Analog Input/Pre-Out Harness, Speaker Output Harness, Subwoofer Output Connector, 6 ft A/B USB Cable

Specification

• Main Channels @ 4 Ω    60 W RMS x 4
• Main Channels @ 2 Ω    90 W RMS x 4
• Main Channels - Bridged @ 4Ω    180 W RMS x 2
• Subwoofer Channel @ 4 Ω    360 W RMS x 1
• Subwoofer Channel @ 3 Ω    480 W RMS x 1
• Subwoofer Channel @ 2 Ω    600 W RMS x 1
• Subwoofer Channel @ 1.5 Ω    N/A
• Frequency Response (Main Channels)    12 Hz - 24 kHz (+0, -1dB)
• Frequency Response (Subwoofer Channel)    12 Hz - 1 kHz (+0, -1dB)
• S/N Ratio, referred to highest rated power (Analog Inputs - Main Channels)    99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to highest rated power (Analog Inputs - Main Channels)    99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to highest rated power (Analog Inputs - Subwoofer Channel)    99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to 1 W (Analog Inputs - Main Channels)    80 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to 1 W (Analog Inputs - Subwoofer Channel)    72 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to highest rated power (Digital Inputs - Main Channels)    100 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to highest rated power (Digital Inputs - Subwoofer Channel)    99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to 1 W (Digital Inputs - Main Channels)    81 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to 1 W (Digital Inputs - Subwoofer Channel)    73 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• Damping Factor @ 2 Ω    >50 / 50 Hz
• Damping Factor @ 4 Ω    >150 / 50 Hz
• THD+N @ Rated Power (Main Channels)    <1% @ 2 Ω per Ch.
• THD+N @ Rated Power (Subwoofer Channels)    <1% @ 2 Ω per Ch.
• Input Voltage Range @ RCA Inputs    200 mV - 16 V RMS
• Min.Copper Power / Ground Wire Gauge    4 AWG wire
• Fuse Rating    80 A (AFS, AGU or MaxiFuse™)
• Height (H)    2.12 in / 54 mm
• Width (W)    11.32 in / 287 mm
• Depth (D)    6.62 in / 168 mm
• Net Weight    6.45 lb / 2.93 kg

What's Included

• 5-Channel amplifier
• Power connector
• 14" Analog Input harness (25-pin D-Sub/8 RCA)
• 18" ABCD Speaker output harness
• Subwoofer output connector
• 18" Speaker wire loom
• "Sub" wire label
• 6' USB cable (Type A USB on one end and Type B USB on other end)
• 4 Corner caps
• Corner cap tool
• 2 Silver thumbscrews
• 2 Black hex cap machine screws
• 2.5mm Hex wrench
• 3mm Hex wrench
• JL Audio logo badge
• Connection Guide
• Registration card
