Product Information

C3-100ct

1-inch (25 mm) Silk Dome Tweeters

The silk dome tweeter is prized by audiophiles for delivering realistic, non-fatiguing, high-frequency performance.

The C3 component tweeters are built with 1-inch silk dome diaphragms that deliver powerful, extended response, on and off axis. Flush-mounting and surface-mounting fixtures are included to fit a wide variety of installation needs. They can also be installed coaxially onto the C3 woofers using the fixtures included with the C3 Component / Coaxial Systems.

Inline 12 dB / octave high-pass filters with tweeter protectors are included with this kit. The C5-075ct is designed to operate above 4 kHz with a minimum high-pass slope of 12 dB / octave.

Sonic character: Clean and Powerful

Sold as a pair.

Specification

• Continuous Power Handling (RMS)    75 W
• Peak Music Power*    225 W
• Recommended Amplifier Power (RMS)    25 - 150 W / Ch.
• System Efficiency    90.0 dB @ 1 W / 1 m
• System Nominal Impedance    4 Ω
• System Frequency Response    4 kHz - 25 KHz ± 3 dB
• Flush Mount Fixture Diameter (A1)    2.12 in / 54 mm
• Surface Mount Fixture Diameter (A2)    1.93 in / 49 mm
• Flush Mount Mounting Hole Diameter (B)    1.875 in / 48 mm
• Flush Mount Mounting Depth (C)    0.71 in / 18.0 mm
• Flush Mount Tweeter Frontal Protrusion (D1)    0.32 in / 8 mm
• Surface Mount Tweeter Frontal Protrusion (D2)    0.95 in / 24 mm

What's Included
