Product Information

W1v3 8-inch Subwoofer (150 W, 4 Ω)

The 8W1v3 is an outstanding choice when space is very tight and amplifier power is moderate. It features shallow mounting depth (3.86 in. / 98 mm) and a compact motor structure, allowing it to comfortably fit in a lot of spaces where a typical 8-inch driver will not. Lacking a pole vent, the rear of the motor structure can be placed directly against an enclosure boundary. Excellent excursion capability and linearity allow it to reproduce sub-bass with shocking extension and quality. Several of JL Audio's proprietary technologies enhance its performance and reliability.

Specification

• Continuous Power Handling (RMS)    150 W
• Recommended Amplifier Power (RMS)    50 - 150 W
• Nominal Impedance (Znom)    4 Ω
• Nominal Diameter    8.0 in / 200 mm
• Overall Diameter (A)    8.5 in / 216 mm
• Mounting Hole Diameter (B)    7.09 in / 180 mm
• Bolt Hole Circle Diameter (C)    7.85 in / 199 mm
• Motor Outer Diameter (D)    4.72 in / 120 mm
• Mounting Depth (E)    3.86 in / 98 mm
• Driver Displacement    0.018 cu ft / 0.51 L
• Net Weight    7.4 lb / 3.4 kg
• Free Air Resonance (Fs)    35.40 Hz
• Electrical “Q” (Qes)    0.451
• Mechanical “Q” (Qms)    5.791
• Total Speaker “Q” (Qts)    0.418
• Equivalent Compliance (Vas)    0.68 cu ft / 19.26 L
• One-Way Linear Excursion (Xmax)*    0.3 in / 8 mm
• Reference Efficiency (no)    0.18%
• Efficiency (1 W / 1 m)**    84.8 dB SPL
• Effective Piston Area (Sd)    32.67 sq in / 0.0211 sq m
• DC Resistance (Re)    4.06 Ω

* Xmax specifications are derived via one-way voice coil overhang method with no correction factors applied.

** Efficiency (1 W / 1 m) is not an accurate indicator of a subwoofer’s output capability and should not be used as a comparison to other subwoofers to determine which one is “louder”.

What's Included

• 10W1v3-4
• Black plastic trim ring
• Owner's manual
