Product Information

All the Hertz Compact Power amplifiers are assembled with high-quality components and feature a complete and by-passable crossover system. The dissipation system is optimized with the heat being transferred to the heat sink and then dissipated through the sides of the amplifier.

With HCP 2 high power systems can be realized: settable both in mono, to drive the subwoofer, and together with another amplifier, for more complex systems; it also features a Bass Boost filters (0 ÷ 12 dB) to enhance low frequencies.

• Channel mode    2 - 1
• Output Power (RMS)  @ 14.4 VDC    2 Ch: 65 W x 2 (4Ω) 2 Ch: 100 W x 2 (2Ω) 1 Ch: 200 W x 1 (4Ω)
• Filters Bypass Yes
• Hi-Pass 80 Hz @ 12 dB/Oct.
• Lo-Pass 50
• Distortion - THD  (100Hz @ 4Ω)    0.01%
• S/N Ratio  (A weighted @ 1V)    103 dB
• Damping factor  (100Hz @ 4Ω)    200
• Size W x D x H mm (in.)    215 x 190 x 50 (8.46 x 7.48 x 1.97)

Specification

What's Included

• Hertz HCP 2
