Product Information

Flax to the max

If you've heard Focal speakers, then you know that their reputation for quality is well-deserved. Focal's designers never hesitate to think outside the box when it comes to speaker innovation. To create their Flax Evo Series speakers and subs, for example, they spent five years developing a super-lightweight, extra-rigid cone material made from a layer of flax fibers sandwiched between two layers of glass fibers. You get the warmth of natural fiber combined with the supreme accuracy of a more rigid cone material.

Small size, big sound

Built at Focal's workshop in France, the P 20 FSE 8" sub delivers performance beyond its size, using superior materials and construction to handle up to 200 watts RMS. At only 3" deep, its shallow-mount design allows it to fit in a compact sealed enclosure, so it's easier to fit in a smaller vehicle. If you're putting together a system, make sure to take a look at Focal's component speaker systems that feature the same "Flax Sandwich" cones.

• 8" 4-ohm component subwoofer
• shallow-mount design
• glass fiber/flax/glass fiber laminate cone with rubber surround
• handles up to 200 watts RMS (400 watts peak)
• frequency response: 35-400 Hz
• sensitivity: 86 dB
• top-mount depth: 3"
• sealed box volume: 0.21-0.38 cubic feet
• grille not included

Specification

• Size    8 -inch
• Impedance    4 ohms
• Cone Material    Flax/Glass
• Surround Material    Rubber
• Ideal Sealed Box Volume (cubic feet)    0.28
• Ideal Ported Box Volume (cubic feet)    N/A
• Port diameter (inches)    N/A
• Port length (inches)    N/A
• Free-Air    No
• Dual Voice Coil    No
• Sensitivity    86 dB at 2.83 volts
• Frequency Response    35 - 400 Hz
• Max RMS Power Handling    200
• Peak Power Handling (Watts)    400
• Top Mount Depth (inches)    3
• Bottom Mount Depth (inches)    N/A
• Cutout Diameter or Length (inches)    7 3/16
• Vas (liters)    9
• Fs (Hz)    35
• Qts    1.3
• Xmax (millimeters)    11

What's Included

• One 8" Shallow mount single voice coil subwoofer
• Rubber trim ring/gasket (installed)
• Six 7/8" Screws
