Product Information

Focal Inside for Ford

Rediscover the pleasure of listening to your favourite songs whilst on the road with Focal’s audio kits

The speaker drivers feature Polyglass technology, which delivers well defined midrange and bass, and the Aluminium inverted dome tweeter, a Focal technology that provides perfect treble reproduction.

Installing this kit does not require any soldering, cable trimming or vehicle modification. The integration is also invisible.

This kit is designed for vehicles that have tweeter slots.

• Quick and easy install
• No modifications needed on the vehicle
• Polyglass cone: natural sound without coloration
• Butyl surround: excellent durability
• Insulation foams provided: perfect sound reproduction, vibrations absorbed

Specification

• 6"x9" component speaker system includes two woofers, two tweeters, and two inline crossovers
• designed to fit a variety of Ford and Lincoln vehicles
• vehicle-specific wire connectors (no cutting required)
• Polyglass woofers with butyl rubber surround
• aluminum/magnesium inverted dome tweeters
• in-line/integrated crossovers
• includes foam rings (insulation between speaker and door opening)
• quick installation (no modifications needed)
• impedance: 4 ohms
• power handling: 75 watts RMS (150 watts peak)
• frequency response: 50-20,000 Hz
• sensitivity: 92.3 dB
• woofer top mount depth: 1-5/8"
• grilles not included

Compatible Vehicles

• Check your vehicle compatibility by contacting us or checking focal inside website.

What's Included

• IS FORD 690 Woofers
• T FORD Tweeters (each with a 4" wire attached containing an in-line crossover)
• Adhesive backed foam gaskets
• Tweeter mounting brackets
• Factory tweeter wire adapters
• Two M4x4mm Machine screws
• Two 10" Wire extensions (woofer)
• Eight 3/4" Screws
• 8 Rivets
• 2 Focal Inside badges
• User manual
• Focal window sticker
