PLUS Improved Sony STARVIS Sensor

The Sony STARVIS™ image sensor that equips the DR750X Plus Series front and rear cameras delivers outstanding low-light performance.

The back-illuminated sensor is capable of capturing an unprecedented amount of detail in both shadows and highlights.

DR750X-1CH DEFINITIVE

With Full HD 1080p performance, the DR750X-1CH provides class-leading protection for your vehicle by recording fluid 60 frames per second video footage via an ultra-wide lens with a 139° viewing angle. A Sony STARVIS image sensor ensures the best possible image quality under any lighting conditions. Also included is GPS logging, Wi-Fi, Cloud-connectivity and impact and motion detection. All this in a stealthy compact design.

• Front HD 60FPS
• 1 Channel
• CLOUD
• 4G READY
• 139°
• Wi-Fi/GPS

The DR750X is also compatible with BlackVue Cloud – a unique suite of LIVE app-based features that remotely connecting you with your vehicle, providing additional functionality including Live View, Remote Video Playback, Video Backup, Realtime Tracking and Emergency Notification Alerts.

The DR750X is upgradable to full 4G always-on Cloud Connectivity, with the addition of the CM100LTE external connectivity module and supplied data SIM, meaning that you are always connected to your dash cam via the BlackVue app, and always able to receive notifications and remotely view video clips in the event of an incident.

PARKING MODE

The DR750X-1CH protects your vehicle even when you’re not around, thanks to BlackVue’s unique Intelligent Parking Mode.

GPS & DUAL BAND WIFI

Built-in GPS adds optional location and speed data overlay to recordings while Wi-Fi provides wireless connection to smartphones.

APP CONTROL

The BlackVue app for iOS & Android provides access the your dash cam’s settings, video files and LIVE BlackVue Cloud features.

FULL HD 60FPS + SONY STARVIS

With Full HD 1080p resolution, smooth 60 frames per second footage, ultra-wide lens with a 139° viewing angle, and SONY’S remarkable industry-leading STARVIS image sensor, the DR750X-1CH provides class-leading protection for your vehicle, in any lighting conditions.

• Model Name    DR750X-1CH
• Channel    1CH
• Highlights    Full HD, Cloud, Wi-Fi, GPS, Sony Sensor, External LTE Module
• Product Dimensions    W 118.5 mm (4.67″) x H 36 mm (1.42″) / 103 g (3.63 oz)
• Memory Support    microSD card up to 256GB
• Recording Modes    – Normal,– Event (Impact Detection / Speed Limit / Manual),– Parking Mode (Impact+Region-based Motion Detection, Timelapse+Events)
• Parking Mode    YES (with 3-wire hardwiring cable – included)
• Parking Mode Event Voice Notifications    YES
• Imaging Sensor    Sony STARVIS™ CMOS Sensor (Approx. 2.1MP)
• Viewing Angle    Diagonal 139°, Horizontal 116°, Vertical 61°
• Resolution Frame Rate    Full HD @60fps * Frame rate may vary during Wi-Fi streaming
• Video Codec    H.264 (AVC)
• Image Quality and Bitrate Front/Rear    Highest (Extreme): 25 Mbps Highest: 12 Mbps High: 10 Mbps Normal: 8 Mbps
• Format Free    YES (Adaptive)
• Event File Overwrite Protection    YES (up to 50)
• SD Card Failure Alert    YES
• Scheduled Reboot    YES
• Video File Extension    MP4
• Wi-Fi    Built-in (802.11 b.g.n)
• Cloud Compatible    YES
• GPS    Built-in (Dual Band : GPS, GLONASS)
• Microphone    Built-in
• Speaker    Built-in
• Impact Sensor    3-Axis Acceleration Sensor
• LED Indicators    Recording LED, GPS/BT LED, LTE/Wi-Fi LED, Front Security LED, Proximity Sensing indicator LED
• Button    Button: Wi-Fi ON/OFF (Tap) Proximity sensor: Mic ON/OFF / Trigger Manual Recording / OFF (configurable)
• Operation Temperature    -20 °C − 85 °C (-4 °F − 185 °F)
• Storage Temperature    -20 °C − 90 °C (-4 °F − 194 °F )
• High Temp Cut Off    Approx. 85 °C (185 °F)
• Backup Battery    Built-in supercapacitor
• Input Power    DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)
• Power Consumption Hour    Normal Mode (WiFi On / GPS On) : 275mA / hour
• Normal Mode (WiFi Off / GPS On) : 240mA / hour Parking Mode (WiFi On / GPS Off) : 220mA / hour Parking Mode (WiFi Off / GPS Off) : 185mA / hour * Actual power consumption may vary depending on use conditions and environment
• Certifications    FCC, CE, RoHS, Telec, WEEE, IC
• software    BlackVue Viewer * Windows 7 or higher and Mac Yosemite OS X (10.10) or higher
• Application    BlackVue Application (Android 5.0 or higher, iOS 9.0 or higher)
• Others    Adaptive Format-Free File Management System
• LTE    External (optional)

• Front Camera
• 32GB Card
• Hardwiring power cable
• Cigarette lighter power cable
• microSD card reader
• Cable clips (5EA)
• Double-sided tape for the Mounting Bracket
• Pry tool
• Quick start guide
