Product Information

The 100 mm (4) midrange is provided with a water-repellent pressed-paper cone, a material providing natural sound. It features a low resonance frequency that allows hi-pass cut-off in the 150-200 Hz range for an excellent mid-low reproduction.

The 25 mm coil and Tetolon dome tweeter features a great extension on both medium and high frequencies and is optimized for off-axis output, for an extended sound stage in the three dimensions, that amplifies the perception of reality in the car cabin.

(*1) = OEM TW placement needed (on A-pillar or door triangle). To install the Audison APBMW T1 tweeter the car must be equipped with the OEM tweeter placement. If it is not available you need to purchase a genuine door triangle or A-pillar from a BMW dealer.

(*2) = Audison APBMW A4E needed. The APBMW A4E is composed by speaker ring adapters which are necessary only on specific car models.

• Specially developed for the upgrade of BMW-Mini featuring factory 2 way systems, to create an extended sound stage in the three dimensions, amplifying the perception of reality in the car cabin.
• 30 cm extension provided featuring Plug & Play connectors, for high flexibility of installation
• Crossover equipped with high quality components and Plug&Play connections.

Specification

• Component 2-way System
• Woofer Size mm (in.) 100 (4)
• Tweeter Size mm (in.) 29 (1.1)
• Power Handling W peak W continuos 100 50
• Impedance Ω 4
• Frequency Response Hz 90 ÷ 23k
• Sensitivity Hz 89
• Crossover Type Hi-Pass: 6 KHz @ 6dB/Oct.
• Component adjustment dB -3; 0
• Woofer Magnet size D x dx hmm (in.) 50 x 29 x 3 (1.97 x 1.14 x 0.12)
• Tweeter Magnet size D x d x h mm (in.) 24,5 x 4 (0.96 x 0.16)
• Weight of one speaker Woofer 0,426 (0.94) Tweeter 0,06 (0.13)
• Voice Coil Ø Woofer 25 (1) Tweeter 25 (1)

What's Included

• Audison Prima APBMW K4M Speakers
